ABB SKKH280/20EH #68602203 High-Power Thyristor/Diode Module

>>> Product Overview <<<

The ABB SKKH280/20EH is a high-power thyristor/diode module designed for advanced industrial applications requiring robust electrical switching and control. This module integrates both thyristor and diode components within a compact package, delivering excellent performance in power conversion and regulation tasks. Engineered by ABB, the SKKH280/20EH ensures reliable operation under demanding conditions, supporting efficient energy management in various systems. Its design optimizes thermal handling and electrical characteristics, making it suitable for high-current environments where precision and durability are crucial. The module is ideal for use in power electronics equipment, enhancing system stability and operational lifespan.

>>> Technical Specifications <<<

>>> Product Features <<<

The SKKH280/20EH module offers several key features to enhance industrial power management systems:

• High Current Capacity: Supports continuous current up to 280 A, enabling efficient handling of heavy electrical loads.
• Integrated Thyristor and Diode: Combines switching and rectification functions in a single module, reducing system complexity.
• Robust Thermal Management: Low thermal resistance ensures effective heat dissipation, enhancing module reliability during prolonged operation.
• High Surge Current Tolerance: Capable of withstanding surge currents up to 4000 A, protecting equipment against transient overloads.
• Compact and Durable Packaging: Designed for easy integration into industrial equipment with mechanical stability and electrical insulation compliance.

>>> Applications <<<

The SKKH280/20EH thyristor/diode module is ideal for use in various industrial electrical systems requiring reliable power control. Typical applications include motor drives, power converters, and static switches within automation equipment. It is well-suited for use in industrial manufacturing plants, energy management systems, and electrical power distribution networks. The module’s high power handling and durability make it a preferred choice for industrial environments demanding precise and robust power regulation technology.
