ABB Tmax XT XT1N 160 TMD R63 3P

>>> Product Overview <<<The Tmax XT1N 160 TMD R63 is a high-performance molded case circuit breaker designed to provide reliable protection for electrical systems in various industrial environments. Manufactured by ABB, this device ensures optimal interruption of fault currents and safeguards critical equipment from overloads and short circuits. Its robust construction and advanced technology enable seamless integration into automation systems, enhancing operational safety and efficiency. The breaker complies with international standards, making it suitable for global industrial applications requiring dependable electrical protection and system control.
>>> Technical Specifications <<<

Parameter
Specification

Model
Tmax XT1N 160 TMD R63

Brand
ABB

Poles
3P (Three Poles)

Rated Current (In)
160 A

Rated Voltage (Ue)
690 V AC

Breaking Capacity (Icu)
50 kA at 415 V AC

Tripping Characteristic
Thermal-Magnetic (TMD)

Rated Frequency
50/60 Hz

Operating Temperature
-25°C to +70°C

Dimensions (HxWxD)
140 mm x 90 mm x 75 mm

Standards Compliance
IEC 60947-2, UL 489
>>> Product Features <<<The Tmax XT1N 160 TMD R63 offers a range of advanced features tailored for industrial electrical protection:
> High breaking capacity ensures effective interruption of short-circuit currents up to 50 kA, providing superior system safety.
> Thermal-magnetic trip unit enables precise protection against overload and instantaneous fault conditions, minimizing equipment damage.
> Compact and modular design allows easy installation and integration into existing electrical panels and automation frameworks.
> Enhanced mechanical endurance supports frequent switching operations without compromising reliability.
> Compatibility with a wide range of accessories and remote control options facilitates system customization and automation upgrades.
>>> Applications <<<The Tmax XT1N 160 TMD R63 circuit breaker is ideal for diverse industrial applications requiring robust electrical protection. It is extensively used in factory automation, power distribution boards, and control panels within manufacturing plants. The device safeguards electrical equipment in heavy industries, infrastructure projects, and commercial buildings, ensuring uninterrupted operation and compliance with safety regulations. Its reliable performance supports critical systems in sectors such as automotive, chemical processing, and energy management.
$ Related Products Recommendation:ABB Tmax XT XT2N 160 TMD R32 3P (ABB)
ABB Tmax XT XT2N 160 TMD R32 3P (ABB)

Parameter	Specification
Model	Tmax XT1N 160 TMD R63
Brand	ABB
Poles	3P (Three Poles)
Rated Current (In)	160 A
Rated Voltage (Ue)	690 V AC
Breaking Capacity (Icu)	50 kA at 415 V AC
Tripping Characteristic	Thermal-Magnetic (TMD)
Rated Frequency	50/60 Hz
Operating Temperature	-25°C to +70°C
Dimensions (HxWxD)	140 mm x 90 mm x 75 mm
Standards Compliance	IEC 60947-2, UL 489

>>> ABB Tmax XT1N 160 TMD R63 – IMAGE 1 <<<

$ Model: Tmax XT1N 160 TMD R63 | Brand: ABB $

>>> ABB Tmax XT1N 160 TMD R63 – IMAGE 2 <<<

$ Model: Tmax XT1N 160 TMD R63 | Brand: ABB $
