ABB Tmax XT XT6N 630 TMD R630 3P

>>> Product Overview <<<The Tmax XT6N 630 TMD R630 is a high-performance molded case circuit breaker designed for reliable protection in demanding industrial environments. Manufactured by ABB, this device ensures superior electrical safety and operational efficiency for medium voltage applications. It integrates advanced trip units to provide precise overload, short-circuit, and earth fault protection, making it an essential component for safeguarding electrical systems. The breaker supports seamless integration with modern automation systems, offering enhanced control and monitoring capabilities. Its robust construction and compliance with international standards guarantee long-lasting performance under harsh conditions, optimizing uptime and reducing maintenance costs.
>>> Technical Specifications <<<

Parameter
Specification

Model
Tmax XT6N 630 TMD R630

Brand
ABB

Rated Current (In)
630 A

Number of Poles
3 Poles

Rated Voltage (Ue)
690 V AC

Breaking Capacity (Icu)
50 kA @ 400 V

Trip Unit Type
Thermal-Magnetic Digital (TMD)

Operating Temperature
-25°C to +70°C

Dimensions (HxWxD)
210 x 130 x 95 mm

Standards Compliance
IEC 60947-2, UL 489
>>> Product Features <<<The Tmax XT6N 630 TMD R630 offers a range of advanced features tailored for industrial electrical protection:
> Digital thermal-magnetic trip unit providing precise protection and fault detection.
> Modular design enabling easy installation and maintenance within electrical equipment.
> High breaking capacity ensuring reliable interruption of short-circuit currents up to 50 kA.
> Integration capability with automation systems for real-time monitoring and control.
> Compact size optimized for space-saving in switchgear assemblies.
>>> Applications <<<The Tmax XT6N 630 TMD R630 is widely used in industrial electrical systems including manufacturing plants, power distribution centers, and automation equipment. It is suitable for protecting electrical circuits in heavy machinery, control panels, and system infrastructure requiring dependable overload and short-circuit protection. This breaker is ideal for environments demanding high reliability and compliance with international safety standards, supporting uninterrupted operation in critical industrial processes.
$ Related Products Recommendation:ABB Tmax XT XT7N 800 TMD R630 3P (ABB)
ABB Tmax XT XT7N 800 TMD R800 3P (ABB)

Parameter	Specification
Model	Tmax XT6N 630 TMD R630
Brand	ABB
Rated Current (In)	630 A
Number of Poles	3 Poles
Rated Voltage (Ue)	690 V AC
Breaking Capacity (Icu)	50 kA @ 400 V
Trip Unit Type	Thermal-Magnetic Digital (TMD)
Operating Temperature	-25°C to +70°C
Dimensions (HxWxD)	210 x 130 x 95 mm
Standards Compliance	IEC 60947-2, UL 489

>>> ABB Tmax XT6N 630 TMD R630 – IMAGE 1 <<<

$ Model: Tmax XT6N 630 TMD R630 | Brand: ABB $

>>> ABB Tmax XT6N 630 TMD R630 – IMAGE 2 <<<

$ Model: Tmax XT6N 630 TMD R630 | Brand: ABB $
