ABB Tmax XT XT3N 250 TMD R100 3P

>>> Product Overview <<<The Tmax XT XT3N 250 TMD R100 3P is a high-performance molded case circuit breaker designed for advanced industrial electrical protection and control. Manufactured by ABB, this device offers reliable interruption capabilities and enhanced safety features for medium voltage applications. It integrates seamlessly into modern automation systems, providing efficient overload and short-circuit protection. The compact design combined with robust construction ensures optimal performance in demanding environments. Suitable for a wide range of electrical distribution systems, this model supports system reliability and operational continuity, making it a critical component in industrial and commercial installations.
>>> Technical Specifications <<<

Parameter
Specification

Model
Tmax XT XT3N 250 TMD R100 3P

Brand
ABB

Rated Current
250 A

Number of Poles
3 Poles

Rated Voltage
690 V AC

Breaking Capacity
50 kA (at 415 V)

Operating Temperature
-25°C to +60°C

Standards Compliance
IEC 60947-2, UL 489

Dimensions (HxWxD)
135 mm x 90 mm x 75 mm

Tripping Unit
Thermal-Magnetic (TMD)

Weight
Approx. 1.5 kg
>>> Product Features <<<The Tmax XT XT3N 250 TMD R100 3P offers several advanced features that enhance electrical system protection and operational efficiency:
> High interruption capacity ensures reliable protection against short-circuits and overloads in industrial electrical systems.
> Thermal-magnetic trip unit provides precise and adjustable tripping characteristics to match specific application requirements.
> Compact and modular design facilitates easy integration into automation control panels and equipment.
> Robust mechanical construction guarantees long service life under harsh industrial conditions.
> Compliance with international standards ensures compatibility and safety across diverse electrical infrastructures.
>>> Applications <<<The Tmax XT XT3N 250 TMD R100 3P is ideal for use in industrial automation environments requiring dependable electrical protection. It is commonly applied in power distribution panels, motor control centers, and electrical switchgear systems. This circuit breaker supports medium voltage equipment protection in manufacturing plants, processing industries, and infrastructure projects. Its design ensures system stability and safety by preventing electrical faults that could disrupt critical operations.
$ Related Products Recommendation:ABB Tmax XT XT3N 250 TMD R250 3P (ABB)
ABB Tmax XT XT4N 250 TMD R250 3P (ABB)

Parameter	Specification
Model	Tmax XT XT3N 250 TMD R100 3P
Brand	ABB
Rated Current	250 A
Number of Poles	3 Poles
Rated Voltage	690 V AC
Breaking Capacity	50 kA (at 415 V)
Operating Temperature	-25°C to +60°C
Standards Compliance	IEC 60947-2, UL 489
Dimensions (HxWxD)	135 mm x 90 mm x 75 mm
Tripping Unit	Thermal-Magnetic (TMD)
Weight	Approx. 1.5 kg

>>> ABB Tmax XT XT3N 250 TMD R100 3P – IMAGE 1 <<<

$ Model: Tmax XT XT3N 250 TMD R100 3P | Brand: ABB $

>>> ABB Tmax XT XT3N 250 TMD R100 3P – IMAGE 2 <<<

$ Model: Tmax XT XT3N 250 TMD R100 3P | Brand: ABB $
