ABB Tmax XT XT4N 250 TMD R100 3P

>>> Product Overview <<<The Tmax XT XT4N 250 TMD R100 3P is a high-performance circuit breaker designed to provide reliable protection and control in electrical distribution systems. Manufactured by ABB, this device ensures optimal safety and operational efficiency for industrial applications. It features advanced trip units and robust mechanical construction, making it suitable for demanding environments where precision and durability are paramount. The Tmax XT series supports seamless integration into modern automation frameworks, contributing to enhanced system reliability and energy management. This circuit breaker is engineered to comply with international standards, ensuring consistent performance across various industrial sectors.
>>> Technical Specifications <<<

Parameter
Specification

Model
Tmax XT XT4N 250 TMD R100 3P

Brand
ABB

Rated Current (In)
250 A

Number of Poles
3

Rated Voltage (Ue)
690 V AC

Breaking Capacity
50 kA (IEC 60947-2)

Operating Temperature
-25°C to +70°C

Dimensions (WxHxD)
90 mm x 140 mm x 75 mm

Trip Unit Type
Thermal Magnetic (TMD)

Mounting
DIN Rail / Panel Mount

Standards Compliance
IEC 60947-2, UL 489
>>> Product Features <<<The Tmax XT XT4N 250 TMD R100 3P offers a range of advanced features designed to enhance electrical system protection and operational efficiency:
> High breaking capacity ensuring effective interruption of fault currents up to 50 kA, safeguarding industrial equipment.
> Thermal magnetic trip unit provides precise overload and short-circuit protection, optimizing system safety.
> Compact design allows for space-saving installation within electrical panels and switchgear assemblies.
> Robust mechanical construction delivers reliable performance under harsh industrial conditions and extended duty cycles.
> Compatibility with automation systems enables seamless integration for remote monitoring and control.
>>> Applications <<<The Tmax XT XT4N 250 TMD R100 3P is ideal for use in a wide range of industrial electrical systems. It is commonly deployed in power distribution networks, motor control centers, and automation equipment to protect circuits from overload and short circuits. This circuit breaker is suitable for applications in manufacturing plants, processing industries, and infrastructure projects where reliable and efficient electrical protection is critical. Its compliance with international standards makes it a preferred choice for global industrial electrical installations.
$ Related Products Recommendation:ABB Tmax XT XT4N 250 Ekip LS/I 160 3P (ABB)
ABB Tmax XT XT4N 250 Ekip LS/I 250 3P (ABB)

Parameter	Specification
Model	Tmax XT XT4N 250 TMD R100 3P
Brand	ABB
Rated Current (In)	250 A
Number of Poles	3
Rated Voltage (Ue)	690 V AC
Breaking Capacity	50 kA (IEC 60947-2)
Operating Temperature	-25°C to +70°C
Dimensions (WxHxD)	90 mm x 140 mm x 75 mm
Trip Unit Type	Thermal Magnetic (TMD)
Mounting	DIN Rail / Panel Mount
Standards Compliance	IEC 60947-2, UL 489

>>> ABB Tmax XT XT4N 250 TMD R100 3P – IMAGE 1 <<<

$ Model: Tmax XT XT4N 250 TMD R100 3P | Brand: ABB $

>>> ABB Tmax XT XT4N 250 TMD R100 3P – IMAGE 2 <<<

$ Model: Tmax XT XT4N 250 TMD R100 3P | Brand: ABB $
